Product Details​


  • U/UTP unshielded CAT3
    ❤ 收藏

  • U/UTP unshielded CAT3

    Application

    Exceeds requirements of ANSI/TIA-568-C.2 Category 3 and

    ISO 11801 Class C channel standards.

    Exceeds the requirements of ANS1/TIA-568-C.2 Category

    3 component standards.

    Descending cable length markings enable easy identification

    of remaining cable which reduces installation time and cable

    scrap.

    Color Availability: Additional cable colors available.

    Patent products:CN200920124769. 9.

    重量：0.000KG
    • 数量：
商品描述

Application

Exceeds requirements of ANSI/TIA-568-C.2 Category 3 and

ISO 11801 Class C channel standards.

Exceeds the requirements of ANS1/TIA-568-C.2 Category

3 component standards.

Descending cable length markings enable easy identification

of remaining cable which reduces installation time and cable

scrap.

Color Availability: Additional cable colors available.

Patent products:CN200920124769. 9.






Mechanical Characteristics
█Cable under the minimum tension>= 400N.
█Conductor elongation: >=15%.
█Jacket before Aging
Tensile Strengthen. 5Mpa
Elongation  >=150%
█Jacket After Aging
Tensile Strength>=12. 5Mpa
Elongation >=125%.
Electrical Characteristics
█Impedance:1-16MHz 100±15(0hms).
█Rated Temperature: 75*C.
█DC Resistance Unbatance(%): Max 2.5.
█DC Resistance 20'C: 111(0hms).
█Pair-to-Gruond Capacitance Unbalance: 330(pF/100M).
█Insulation Resistance: >5000MO*Km.
█Dielectric strength: DC 2500V 2S.
HI-SUN U/UTP unshielded CAT3
